Handheld Drone Detection & Positioning Device | Multi-Band Passive UAV Tracking System
The LDSKL03 Handheld Drone Detection and Positioning Device is an advanced passive detection system based on CRPC 2.0 technology, designed to accurately detect, identify, and track unauthorized UAVs. It can extract and analyze real-time flight data such as drone SN, model, geo-location, altitude, speed, trajectory, and pilot position without emitting any electromagnetic signals.
This compact, lightweight device supports multi-band detection across 900MHz, 1.2GHz, 2.4GHz, 5.8GHz, and WiFi frequencies, providing up to 3km+ detection range depending on the environment. It enables multi-target tracking, black/white list management, pilot navigation, and real-time image stream recording for enhanced situational awareness.
Its IP54-rated rugged design, 6-inch display, and portable form factor make it suitable for event security, critical infrastructure protection, and perimeter monitoring. With network management and wireless intercom functions, multiple units can be linked for collaborative operations.
Applications include:
- Security and public safety patrols
- Border and restricted airspace monitoring
- Industrial facility and infrastructure protection
- Event venue UAV surveillance
Product Specifications
| Category | Parameter | Specification | Remarks |
| Detection | Working Principle | Passive detection | No electromagnetic emission |
| Detection Bands | 900MHz, 1.2GHz, 2.4GHz, 5.8GHz, WiFi | - |
| Sensitivity | ≤ -100dBm | - |
| Detection Distance | 0–3km+ | Environment & drone type dependent |
| Response Time | ≤5s | - |
| Simultaneous Detections | ≥10 drones | - |
| Trajectory Tracking | ≥10 drones | - |
| Position Accuracy | ≤3m | For decodable UAVs |
| Supported Protocols | DJI OC, Mavlink, Parrot, TBS CrossFire | - |
| Performance | Dynamic Detection Speed | ≥60km/h | For decodable UAVs |
| Display | Screen Size | 6.0 inch | - |
| Power | Battery Capacity | 12000mAh | Built-in lithium |
| Operating Time | 3–4h | - |
| Charging Power | DC 9V, 2A | - |
| Charging Time | ≤3h | 0–100% |
| Power Consumption | ≤15W | - |
| Interfaces | External Ports | Type-C, SMA (×2), 3.5mm audio, SIM card slot | - |
| Mechanical | Size | 177 × 89 × 29.5mm ±2mm | Without antenna |
| Weight | ≤580g (main unit) | ≤46g per antenna |
| Environmental | Operating Temp | -20℃ to +50℃ | - |
| Storage Temp | 15–25℃ | RH 25–65% |
| Protection | IP Rating | IP54 | Dust & splash resistant |
Product Pictures
Lead Time
| Quantity(PCS) | <100pcs | <500 | 500-1000 | >1000 |
| Lead time(Days) | 3 | 3-5 | 7-12 | To be negotiated |
Customization
| Item | Logo | Frequency | Power | Packing |
| MOQ(PCS) | 1 | 1 | 1 | 1 |
Company Profile
Shenzhen Ladasky Technology Co., Ltd. is a national high-tech enterprise specializing in advanced technologies for UAV defense and low-altitude security systems. We focus on RF sensing, signal analysis, and active interference solutions. Our product portfolio includes UAV detection modules, RF suppression units, and navigation signal simulation systems.
Ladasky is committed to delivering precise, efficient, and intelligent low-altitude protection solutions. Our systems have been widely applied in government agencies, public security, and critical infrastructure protection. Driven by innovation, we are dedicated to building industry-leading UAV control and management technology platforms.
Packing and Delivery
| Selling Units: | Single item |
| Single package size: | 20X10X5 cm |
| Single gross weight: | 0.2kg |
| Package Type: | Each piece is individually packed into a bag and then packed into a carton. |
