200W GaN RF Power Amplifier Module 2400-2500MHz for Industrial Use

Name: 200W GaN RF Power Amplifier Module 24002500MHz for Industrial Use
Brand: LDSK
Price: 1 USD

Quality 200W GaN RF Power Amplifier Module 2400-2500MHz for Industrial Use for sale

Brand Name : LDSK

Model Number : LDSK-TZ-GAN-9

Certification : Guangdong, China

Place of Origin : China

MOQ : 1

Payment Terms : D/A,D/P,T/T,Western Union,MoneyGram,Paypal

Supply Ability : 50000 pcs per month

Delivery Time : 1-3 workdays

Frequency And Power : 2400–2500MHz 200W

Operating Voltage : 28V

Operating Ambient Temperature : -40～+55℃

Highlight : FPV Anti-Drone Module, 80W Anti-Drone Module, DJI Anti-Drone Module

Contact Now

High Power GaN RF Power Amplifier 200W | 2400–2500MHz Wideband Module | Industrial & Communication Applications

Item Detials:

The LDK-TZ-GAN-200 High Power GaN RF Power Amplifier Module is engineered with advanced Gallium Nitride (GaN) technology to deliver exceptional RF amplification performance in the 2400–2500MHz frequency range. Designed for demanding industrial and communication systems, this compact module provides 200W maximum output power with high efficiency and excellent environmental adaptability.

Housed in a durable metal enclosure, it supports a wide operating voltage range and integrates optimized matching networks for minimal signal loss. Featuring RS-485 monitoring, thermal protection, over-current protection, and VSWR protection, it ensures stable and reliable operation even in harsh environments.

Applications include:

Industrial RF systems
Communication equipment testing
Wireless data transmission systems
Research and development projects

Product Specifications:

Parameter	Specification	Unit	Remarks
Model	LDK-TZ-GAN-200	-	-
Frequency Range	2400–2500	MHz	With built-in high-efficiency sweeper
Working Voltage	28	V	-
Max Output Power	52.7	dBm	≤13.0A
Power Efficiency	49	%	Typical
Output VSWR	≤1.50	-	-
Operating Temperature	-40 to +55	℃	-
Power Stability	1.5	dB	-20℃ to +75℃
Power Supply Requirement	≥14	A	For maximum output power
Control Interface	2×4 pin	-	RS-485 communication, PA enable control
Protection Features	-	-	Thermal, over-current, VSWR protection
RF Output Connector	N-F	-	Female
Dimensions	154.5 × 73 × 26.5	mm	Excluding connector
Mounting Hole Size	149.5 × 67.7	mm	M3.0 × 10
Housing Material	Metal	-	High reliability
Cooling Requirement	-	-	Adequate ventilation or heatsink recommended

Product Pictures:

200W GaN RF Power Amplifier Module 2400-2500MHz for Industrial Use

Lead Time

Quantity(PCS)	<100pcs	<500	500-1000	>1000
Lead time(Days)	3	3-5	7-12	To be negotiated

Customization

Item	Logo	Frequency	Power	Packing
MOQ(PCS)	1	1	1	1

Company Profile:

200W GaN RF Power Amplifier Module 2400-2500MHz for Industrial Use

Shenzhen Ladasky Technology Co., Ltd. is a national high-tech enterprise specializing in advanced technologies for UAV defense and low-altitude security systems. We focus on RF sensing, signal analysis, and active interference solutions. Our product portfolio includes UAV detection modules, RF suppression units, and navigation signal simulation systems.

Ladasky is committed to delivering precise, efficient, and intelligent low-altitude protection solutions. Our systems have been widely applied in government agencies, public security, and critical infrastructure protection. Driven by innovation, we are dedicated to building industry-leading UAV control and management technology platforms.

Packing and Delivery:

Selling Units:	Single item
Single package size:	20X10X5 cm
Single gross weight:	0.2kg
Package Type:	Each piece is individually packed into a bag and then packed into a carton.

200W GaN RF Power Amplifier Module 2400-2500MHz for Industrial Use

FAQ

1.Why Choose us?
We have professional knowledge, sincere service, patient reply, and excellent team. Can give you a comfortable buying experience.

2.What is the process of placing an order?
First, you send products you like.
Second, we send information details and quotations.
Third, you can consult any questions about our products.
Fourth, confirm the order, we will send PI, payment link.
Fifth, after the goods are packaged, we will send pictures to confirm the products, and send you the express tracking number.
Sixth, after receiving the goods, you are welcome to give us product evaluations.

3. How to contact us?
