100W GaN RF Power Amplifier 300-1500MHz for Anti-Drone Systems

Name: 100W GaN RF Power Amplifier 3001500MHz for AntiDrone Systems
Brand: LDSK
Price: 1 USD

Quality 100W GaN RF Power Amplifier 300-1500MHz for Anti-Drone Systems for sale

Brand Name : LDSK

Model Number : LDK-TZ-KGN-100W

Certification : Guangdong, China

Place of Origin : China

MOQ : 1

Payment Terms : D/A,D/P,T/T,Western Union,MoneyGram,Paypal

Supply Ability : 50000 pcs per month

Delivery Time : 1-3 workdays

Frequency And Power : 300–1500MHz 100W

Operating Voltage : 28-32V

Operating Ambient Temperature : -10～+55℃

Size : 170 × 77 × 24.5mm

Highlight : FPV Anti-Drone Module, 100W Anti-Drone Module, DJI Anti-Drone Module

Contact Now

High Efficiency GaN RF Power Amplifier 100W | 300–1500MHz Broadband Signal Boost Module for Anti-drone Use

Item Detials:

The LDK-TZ-KGN-100W High Power GaN RF Power Amplifier Module is built with advanced Gallium Nitride (GaN) technology, delivering high efficiency, high gain, and wide bandwidth performance across the 300–1500MHz frequency range. Designed for industrial and communication applications, it ensures 100W continuous output power with exceptional thermal stability and gain flatness.

Housed in a robust metal enclosure with optimized matching networks and thermal management, this compact amplifier integrates over-temperature protection, VSWR protection, and advanced control interfaces. It supports both RS-485 and TTL communication protocols, enabling real-time monitoring of temperature, current, voltage, and RF output power.

Applications include:

Industrial RF transmission systems
Wireless communication testing
Research and development projects
RF laboratory applications

Product Specifications:

Parameter	Specification	Unit	Remarks
Model	LDK-TZ-KGN-100W	-	-
Frequency Range	300–1500	MHz	-
Working Voltage	32	V	Range: 28–32V
Max Output Power	100	W	100W @ 7.2A Typical
Power Amplifier Efficiency	43	%	@100W
Maximum Gain	45	dB	-
Gain Flatness	≤5	dB	-
Standard Input Power	5	dBm	-
Max Non-Damaged Power	≤10	dBm	-
Output Port VSWR	≤2	-	No power, network score test
Operating Temperature	-10 to +55	℃	-
Power Stability	±1.0	dB	-40℃ to +55℃
Power Supply Requirement	≥9A @ +32Vdc	-	100W CW output
Control Interface	RS-485 / TTL	-	2.54mm 2×4 pin
Monitoring Functions	Temp, current, voltage, RF output power	-	-
RF Connectors	Input: SMA, Output: N-F	-	-
Dimensions	170 × 77 × 24.5	mm	-
Weight	900	g	-
Mounting Hole Size	152.3 × 71.5	mm	M3.0 × 4
Housing Material	Metal	-	High reliability

Product Pictures:

100W GaN RF Power Amplifier 300-1500MHz for Anti-Drone Systems

Lead Time

Quantity(PCS)	<100pcs	<500	500-1000	>1000
Lead time(Days)	3	3-5	7-12	To be negotiated

Customization

Item	Logo	Frequency	Power	Packing
MOQ(PCS)	1	1	1	1

Company Profile:

100W GaN RF Power Amplifier 300-1500MHz for Anti-Drone Systems

Shenzhen Ladasky Technology Co., Ltd. is a national high-tech enterprise specializing in advanced technologies for UAV defense and low-altitude security systems. We focus on RF sensing, signal analysis, and active interference solutions. Our product portfolio includes UAV detection modules, RF suppression units, and navigation signal simulation systems.

Ladasky is committed to delivering precise, efficient, and intelligent low-altitude protection solutions. Our systems have been widely applied in government agencies, public security, and critical infrastructure protection. Driven by innovation, we are dedicated to building industry-leading UAV control and management technology platforms.

Packing and Delivery:

Selling Units:	Single item
Single package size:	20X10X5 cm
Single gross weight:	0.2kg
Package Type:	Each piece is individually packed into a bag and then packed into a carton.

100W GaN RF Power Amplifier 300-1500MHz for Anti-Drone Systems
